Hydraulic Power Units

Vane Pump Hydraulic Power Unit

Vane Pump Hydraulic Power Unit

Piston Pump Hydraulic Power Unit

Piston Pump Hydraulic Power Unit

Inverter Hydraulic Power Unit

Inverter Hydraulic Power Unit

Hydraulic Turret Power Unit

Hydraulic Turret Power Unit

Hydraulic Turret Power Unit

Specifications

Series Number Description

JSP

10

1

V

0

A1

MA

1

Series

No.

Tank

Capacity

Motor

Type

Pump

Type

Pump

Flow

Pressure

Range

Manifolds Position

Circuit

Structure

Vane Pump Hydraulic Power Unit
Model.	EX : JSP-10-1-V-0-A1-MA-1
NO.	Tank Capacity
10	10L
20	20L
30	30L
60	60L
80	80L
100	100L
120	120L
Others	Others
NO.	Motor
1	0.75kw-4P
2	1.5kw-4P
3	2.2kw-4P
4	3.7kw-4P
5	5.5kw-4P
6	Others
NO.	Pump
V	Variable Vane Pump
NO.	Flow
0	8.3 cc
1	11.1 cc
2	16.7 cc
3	22.2 cc
4	Others
5	其他
6	其他
7	其他
NO.	Pressure Range
A1	15-35 kg
A2	35-50 kg
A3	50-70 kg
A4	Others
A5	其他
NO.	Manifolds Position
MA	On the tank panel
MA	Circuits not limited
MB	On the pump
MB	Circuits at most three-way
NO.	Circuit Structure
1	02-1 Station
2	02-2 Station
3	02-3 Station
4	Others

Piston Pump Hydraulic Power Unit
Model.	EX : JSP-10-1-P-0-A1-MA-1
NO.	Tank Capacity
10	10L
20	20L
30	30L
60	60L
80	80L
100	100L
120	120L
Others	Others
NO.	Motor
1	0.75kw-4P
2	1.5kw-4P
3	2.2kw-4P
4	3.7kw-4P
5	5.5kw-4P
6	Others
NO.	Pump Type
P	Variable Piston Pump
NO.	Pump Flow
0	8 cc
1	16.5 cc
2	22 cc
3	36 cc
4	46 cc
5	70 cc
6	100 cc
7	Others
NO.	Pressure Range
A1	10-40 kg
A2	20-70 kg
A3	30-140 kg
A4	40-210 kg
A5	Others
NO.	Manifolds Position
MA	On the tank panel
MA	Circuits not limited
MB	On the pump
MB	Circuits at most three-way
NO.	Circuit Structure
1	02-1 Station
2	02-2 Station
3	02-3 Station
4	Others

Dimensions

	Dimensions ( mm )
Model	A	B	C	D	E	F	G	H	I	J	K	L	M
JSP-10-0.75-V-A	440	420	380	400	155	160	70	45	40	145	240	290	300
JSP-10-0.75-V-A	440	420	380	400	155	160	70	45	40	145	240	290	300
JSP-10-1.5-V-A	480	435	380	400	155	160	70	45	40	145	240	290	300
JSP-20-1.5-V-A	510	540	380	400	255	260	170	45	40	145	240	290	300
JSP-30-2.2-V-A	580	520	560	580	185	190	100	45	40	145	240	290	300
JSP-20-1.5-P-A	510	540	380	400	255	260	170	45	40	145	240	290	300
JSP-30-1.5-P-A	580	520	560	580	185	190	100	45	40	145	240	290	300
JSP-30-2.2-P-A	580	520	560	580	185	190	100	45	40	145	240	290	300
JSP-30-2.2-P-A	580	520	560	580	185	190	100	45	40	145	240	290	300
JSP-60-3.7-P-A	680	550	560	580	255	260	170	45	40	205	360	410	420
JSP-60-3.7-P-A	680	550	560	580	255	260	170	45	40	205	360	410	420
JSP-80-3.7-P-A	680	570	650	680	295	300	225	45	40	205	360	410	420
JSP-100-3.7-P-A	680	670	650	680	395	400	325	45	40	205	360	410	420
JSP-100-5.5-P-A	680	670	650	680	395	400	325	45	40	205	360	410	420

Model	Tank Capacity	Motor	Pump	Oil Limit
Serial No.	L	KW	CC	MAX	MIN
JSP-10-0.75-V-A	10	0.75-4	8.3	10	7
JSP-10-0.75-V-A	10	0.75-4	11.1	10	7
JSP-10-1.5-V-A	10	1.5-4	11.1	10	7
JSP-20-1.5-V-A	20	1.5-4	16.7	20	16
JSP-30-2.2-V-A	30	2.2-4	16.7	30	25
JSP-20-1.5-P-A	20	1.5-4	8	20	16
JSP-30-1.5-P-A	30	1.5-4	16.5	30	25
JSP-30-2.2-P-A	30	2.2-4	16.5	30	25
JSP-30-2.2-P-A	30	2.2-4	22	30	25
JSP-60-3.7-P-A	60	3.7-4	16.5	60	45
JSP-60-3.7-P-A	60	3.7-4	22	60	45
JSP-80-3.7-P-A	80	3.7-4	22	80	65
JSP-100-3.7-P-A	100	3.7-4	22	80	65
JSP-100-5.5-P-A	100	5.5-4	36	80	65
